- Ikuti IEEE 802.3 Ethernet dan Protokol Fast Ethernet IEEE802.3u
- Perangkat Bertenaga (PD) yang sesuai dengan POE IEEE 802.3af/at
- Mode: Mode Normal/Perpanjang+Mode Anjing Pengawas
- Port 1~8 dilengkapi kemampuan catu daya POE dan dapat digunakan sebagai daya pada perangkat Ethernet
- Crossover MDI/MDIX otomatis untuk semua port
- Mendukung dupleks penuh berdasarkan IEEE802.3x dan setengah dupleks berdasarkan Tekanan Balik
- Penerusan kecepatan kawat tanpa pemblokiran
- Alamat MAC pembelajaran otomatis & penuaan otomatis
- Casing baja, total anggaran daya POE sebesar 120W
- Cukup Pasang dan Mainkan
Spesifikasi Hardware :
Interface | 8 10/100M POE ports (Data /Power) 2 10/100M RJ45 ports (Data) |
LED | PWR: Lighting - The device is powered on normally AI: Lighting - The intelligent mode is enabled Port: Lighting - Port link is normal Blinking - Data in transit |
MAC Address Table Size | 2K |
Jumbo Frame | 2048 byte |
Store & Forwarding | Yes |
Mode | Normal Mode Extend+Watch Dog Mode |
Cabling type
| 100Base-TX: Cat 5e or better UTP/STP(≤100m) 10Base-TX: Cat 5e or better UTP/STP(≤250m) |
Power Input POE Standards | Single port maximum power 30W Whole switch maximum power 120W Supporting over-current, over-voltage and short-circuit protection Supporting Soft Start of High Power PD Support sequential boot-up Power Supply Pin:12+/36- AC 100~240V 50-60Hz |
Spesifikasi Software :
Data Transfer Rate | 10Mbps(Half-duplex and Full-duplex) 100Mbps(Half-duplex and Full-duplex) |
Basic function
| Follow IEEE 802.3 Ethernet and IEEE802.3u Fast Ethernet Protocol Supports POE IEEE 802. 3af/at compliant Powered Device (PD) Store-and-forward switching scheme Support IEEE802.3X full duplex and Backpressure half duplex MAC address auto-learning & auto-aging |
Standards
| IEEE 802.3 10BASE-T Ethernet IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3af/at, Power over Ethernet IEEE 802.3x Flow Control |
Switching Capacity | 2G |
